Measurement

Tools
ToolPictureQuantityRemarks/Links
DANIU™ LCR-TC1 1.8inch Colorful Display Multi-functional TFT Tester

1
Features

It can be widely used to detect NPN and PNP transistor, capacitor, resistor, diode, triode, N-channel and P-channel MOSFET, IGBT, JFET, triac and battery etc.
It can also be used to detect infrared wave forms.
It also can detect zener diode and has the function of self-calibration.
After detection, align the infrared remote control with the "IR" light, then press the button in the remote control, if the detector successfully decode it, it will display the data code and infrared wave form.
One button operation, automatically detect and shutdown, and you can press the multi-functional button to close the detector too.
Put the pins of component in corresponding area, then dial the little handle and the detector will test it automatically, finally the results will display on the back light TFT screen clearly.
Not like the usual black and white display, this detector will show results in color.

Specifications

Display: 1.8 inch TFT Screen
Diode Range: < 4.5 V
Zener Diode:Transistor Detect Area: 0.01-4.5 V
Zener Diode Detect Area: 0.01-30 V
Triac Range: IGT < 6 mA
Capacitance: 25 pF-100 mF
Resistor: 0.01-50 MΩ
Inductance: 0.01 mH-20 H
Battery: 0.1-4.5 V
Power Mode: Rechargeable Lithium Battery (INCLUDED)
Item Size: 8.8x8x2.8 cm
Item Weight: 111.5 g

Manual
KEWEISI 4V-20V 0-3A USB Charger Power Battery Meter

2
Features

  • It can measure the USB-powered devices empty and easy to use and practical.
  • Compact and easy to carry, no additional power supply, plug and play.
  • It can easily measure the output voltage of the USB port and the device operating current or load voltage.
  • Detect any USB charger such as PC USB, home charger, car charger.
  • Wide range of applications, any phone, any electronic product.
  • Suitable for factories, laboratories and personal use.

Specification

Voltage : 4 V-20 V, ± 1%
Current : 0-3 A, ± 1%
Time : 0-99 H
Battery Capacity : 0-99999 mAh
Size : 7.2x2.2x1.1 cm
Lipo Battery Low Voltage Tester 1S-8S Buzzer Alarm

2
Use for 1-8s Lipl/Li-ion/LiMn/Li-Fe
  • Voltage detection pricision: 0.01 V
  • Unit voltage display range: 0.5V-4.5 V
  • Total voltage display range: 0.5V-36 V
  • 1S test mode voltage range: 3.7v-30 v
  • Low voltage alarm mode for 2-8S
  • Alarm set value range: OFF-2.7 V-3.7 V

  1. When the voltage is below the set value,it will buzzer with red LED light, pre-set value 3.3V
  2. Push key which can change the voltage settings and save
  3. Size: 3.9x2.4x0.9 cm
  4. For 1S-8S / Lipo / Li-ion / Li Mn / Li-Fe Battery

Features
  • This product is using for detecting 1S-8S lithium battery
  • Detect the voltage of each battery core automatically, support reverse connection protection
  • To know the working state of your battery anytime, protect the battery from overcharge and over discharge
  • The red LED will flash,the buzzer will beeping when the voltage is below the set point
  • The factory default setting is 3.3 V, press the button to change the voltage setting, and it will save your current setting automatically
Multimeter DT830A
1
Spänningsmätning
DC-mätning
  • 200 mV (100 µV)
    2000 mV (1 mV)
    20 V (10 mV)
    200 V (100 mV)
    1000 V (1 V)

AC-mätning
  • 200 V (100 mV)
  • 750 V (1 V)

DC strömstyrka
  • 200 µA (100 nA)
  • 2000 µA (1 µA)
  • 20 mA (10 µA)
  • 200 mA (100 µA)
  • 10 A (10 mA)

Motståndsmätning
  • 200 Ω (0,1 Ω)
  • 2000 Ω (1 Ω)
  • 20 kΩ (10 Ω)
  • 200 kΩ (100 Ω)
  • 2000 kΩ (1 kΩ)

Diod och buzzer
  • Diod: Testspänning ca 2,8 V, ström ca 1 mA. Det ungefärliga spänningsfallet i mV kommer att visas.
  • Buzzer: Buzzer låter när den är mindre än ca 50 Ω.

Batteritest
  • 1,5 V (ström 20 mA)
  • 9 V (ström 5 mA)

Batteri: 9V 6F22


Multimeter Uni-T UT33A
1Autorange

Funktioner
  • Summer: Ja
  • Autorange: Ja
  • Belyst display: Nej
  • Kan mäta kontinuitet, förstärkningsfaktor (hfe) och spänningsfall över halvledare (t.ex. diod)

Specifikationer
  • DC-spänning 200 mV-500 V  +/- (0,8 % + 1)
  • AC-spänning 200 mV-500 V +/- (1,2 % + 3)
  • DC-ström 200 μA-10 A +/- (1 % + 2)
  • AC-ström 200 μA-10 A +/- (1,5 % + 5)
  • Resistans 200 Ω-40 MΩ +/- (1 % + 2

Batteri: 2xAAA

Multimeter M-830B
1
Spänningsmätning
DC-mätning
  • 200 mV (100 µV)
    2000 mV (1 mV)
    20 V (10 mV)
    200 V (100 mV)
    1000 V (1 V)

AC-mätning
  • 200 V (100 mV)
  • 750V (1 V)

DC strömstyrka
  • 200 µA (100 nA)
  • 2000 µA (1 µA)
  • 20 mA (10 µA)
  • 200 mA (100 µA)
  • 10 A (10 mA)

Motståndsmätning
  • 200 Ω (0,1 Ω)
  • 2000 Ω (1 Ω)
  • 20 kΩ (10 Ω)
  • 200 kΩ (100 Ω)
  • 2000 kΩ (1 kΩ)

hFE
  • Vcc about 3V, Ib about 10µA, display hFE 1-1000

Batteri: 9V 6F22

Luxorparts Servotestare

1Servotestare för upp till tre servon. Tre lägen: manuellt via vredet, mittposition och automatiskt fram och tillbaka. 3-polig standardanslutning.

Drivs med 4,8-6 V.
